Geotextile Net



GEO Matts

Woven out of double layers of geotextile casting, GEOMatts can be connected with each other to form a variety of mattress systems which provide superior solution to erosion control, in virtue of flexible polyester or concerete, GEOMatts fits diverse terrain perfectly and relieves hydrostatic pressure significantly at the same times, which results in effective revetment of great stability.

Why GEOMatts?

First of all, GeoMatts is manufactured by plants certified as meeting the requirements of ISO 9001:2000, which ensures that it is reliable and worthy of your trust. Furthermore, GEOMatts proved so efficient and economical in extensive practical fields that it has been regarded as no longer just an alternative but rather the most desirable solution.

  • It is easy to carry and apply, thus economical of time and cost.
  • Quick installation results in minimal disturbance to environment and great help to emergency repair.
  • Attributed to flexibility high tensile strength and superior permeability, GEOMatts drains water effectively and achieves permanent stability.
  • GEOMatts is designed to resist erosion and weathering, and provide firm foundation for vegetation.
  • GEOMatts can be tailored, stitched, and installed to fit various field, and the structural integrity is always maintained.

When and Where GEOMatts?

GEOMatts has proved to perform well for an extensive range of projects. In general, GEOMatts functions as,

  • Marine and riverside revetment
  • Ground Sills
  • Slope stabilization
  • Erosion and scouring control
  • Structures reinforcement and protection (such as piles, levees, piers, abutment, etc)
  • Sustaining vegetation.

Which GEOMatts?

We provide standard grades of GEOMatts suitable for most practical applications to assist in construction at a competitive cost.

Grades Properies GEOMatts I GEOMatts II
Tensile Strength (KN/M) Warp ≧40
Weft ≧20
Warp≧120
Weft≧110
Elongation (%) Warp≦22
Weft≦22
Warp≦43
Weft≦25
Water Permeability (L/㎡/sec) ≧20 ≧18
Apparent Opening Size AOS (μ) ≦330 ≦300
Mass Per Unit (g/㎡) ≧400 ≧420
Width (m) ≧5 ≧5
Material (Warp / Weft) PA/PE PA/PE
Void Size (c㎡) 17 × 17 30 × 30

Besides grades above, versatility of design of GEO Matt are ready to be custom-made to meet specific requirement.

We are also geotextile manufacturer & supplier. Geotextile is formed by the high pulling force strength polyethylene fiber bundle that belongs to the net using in environmental engineering. It has the function of anti-ultraviolet ray, material decomposition, PH of PVE protection film. Its mainly usage is in the different large fundamental engineering construction.

The mainly use is in the hillside land developmental engineering, roadway construction engineering, trash burial ground developmental engineering, golf field green, and special design and flexible application in any soil and civil engineering. This product has the resistant potential change, high intensity, light material, and high flexibility.

Geogrid Net


Material : HDPE Coated PVC


Product information Unit TGB-020 TGB-030 TGB-040 TGB-060 TGB-080 TGB-100 TGB-150 TGB-200 TGB-400 TGB-600
Length m 50 50 50 50 50 50 50 50 50 50
Width m 4 4 4 4 4 4 4 4 4 4
Weight g/sqm 190 245 300 340 400 450 570 770 1400 2100
Tension Strength MD KN/m 20 30 40 60 80 100 150 200 400 600
CD KN/m 20 30 30 30 30 30 30 30 50 50
Elongation MD % < 10 < 10 < 10 < 10 < 10 < 10 < 11 < 13 < 14 < 15
Aperture Size MD±20% mm 27 25 24 23 22 20 19 18 18 15
CD±20% mm 28 28 28 28 28 28 28 28 28 28
Weight of roll Kg 38 49 60 68 80 90 114 154 280 420
20' container sqm 20,000 20,000 18,000 16,000 14,000 13,000 10,800 9,000 6,000 4,000
40' container sqm 40,000 40,000 36,000 32,000 28,000 26,000 21,600 18,000 12,000 8,000
40' Dry High Cute sqm 58,500 58,500 52,650 46,800 40,950 38,025 31,590 26,325 17,550 11,700


TGB-40
TGB-60
TGB-80

TGB-100
TGB-150
TGB-400
